Aluminum Window Sliding Insulated System S500 PHOS
Minimalist design lover? The S500 PHOS aluminum window series has clean lines and natural light.
Contact us
Home
/
Products
/
Aluminum Window Sliding Insulated System S500 PHOS
Advantages
Patented magnetic technology for sliding aluminium systems, offering limitless dimensions and typologies
Guaranteed ease in sliding sashes weighing up to 1000 Kg, without the need for electricity or additional space to install magnetic technology.
Certified durability, delivering unmatched resilience in highly corrosive environments.
Minimal design with concealed profiles and clear, symmetrical lines for maximum natural light.
Narrow interlocking profile of only 25 mm face width for unobstructed views.
Easy and safe access with the Eclipse version, with a fully concealed bottom track covered with the floor finish, providing a flat surface.
Ultimate minimal design in the Total Eclipse version, with all tracks covered by the ceiling, floor, and walls, resulting in a seamless appearance.
Certificates
No items found.
Product Benefits
WINDOW TYPE
Sliding
THERMAL INSULATION
Yes
EXTERIOR SHAPE
Flat
Technical Details
SASH DEPTH
50 mm
SASH WEIGHT
up to 1000kg
MAXIMUM GLAZING THICKNESS
36 mm
MECHANISM
alumil
SEALING METHOD
Perimetrical with tri-fin brushes
MINIMUM THRESHOLD HEIGHT
0 mm
TYPE OF THERMAL INSULATION
Polyamides, ABS
Performance
UW
1,2 W/m2K
WATER TIGHTNESS
7A
AIR PERMEABILITY
3
WIND LOAD RESISTANCE
C3
Product Options
TYPES OF TYPOLOGY
Horizontal sliding sashes, Meeting stile, Combinations with fixed lights, Combinations with fly-screen
INSECT SCREEN
SURFACE TREATMENTS
Thermal Performance
Double horizontal sliding sash
Single sliding sash with fixed light
2 sashes / 2 track IFS
Triple horizontal sliding sash
Fixed / 2 sashes
Four horizontal sliding sashes with meeting stile
Double horizontal sliding sash meeting stile with fixed lights
Corner typology with four sliding sashes
Corner typology with two sliding sashes and fixed lights
Multitrack
