Folding Door System MF65

MF65 Series is a thermally insulated system for folding doors with minimal design and little visible aluminum. It offers excellent thermal insulation, and high watertightness performance and is ideal for large constructions, remaining flawless over time.

/

/

Folding Door System MF65

Advantages

Elevates the aesthetics of your place, thanks to its minimal design and very thin profiles (88mm).

Achieves top performance in terms of air permeability, watertightness & wind load resistance.

Increases energy efficiency and cost savings, thanks to the top thermal insulation (up to Uw=1.1 W/m2K).

Provides enhanced levels of burglary protection, with quadruple latches, 3-point locking and a special anti-lift mechanism.

Allows robust large constructions (up to 1.3m width or up to 3m height).

Offers a wide variety of solutions with an odd number of vents, double or triple glazing (24-44mm), standard and low threshold.

Ensures smooth and flawless operation, without any problems, even at the open position, thanks to its high-quality, heavy-duty roller hinges.

Certificates

No items found.

Product Benefits

THERMAL INSULATION

Yes

AESTHETICS

minimal, low sight line

OPERATION

bottom slide

APPLICATIONS

residential with up to 1.3m vents width, commercial with up to 3.0m vents height

Technical Details

SASH WIDTH

65 mm

GLAZING

24-44 mm

POLYAMIDE

up to 32mm

EXTRA INSULATING FITTINGS

ALUMIL NRG bars and PE insulation foam

MAIN GASKET

EPDM

LOCKING

5-point (door) & 4-point (vents)

VISIBLE ALUMINIUM

88mm sash/sash

MAXIMUM WEIGHT

140 Kg/vent

MAXIMUM HEIGHT

3.0 m

MAXIMUM PANEL WIDTH

1.3 m

Performance

UF

from 2.2 W/m²K

WATER TIGHTNESS

8A

AIR PERMEABILITY

CLASS 3

WIND LOAD RESISTANCE

CLASS C2/B2

Product Options

TYPES OF TYPOLOGY

INSECT SCREEN

SURFACE TREATMENTS

Thermal Performance

Odd number of vents on one side

Odd number of vents plus door

Odd number of vents on both sides (meeting stile)

High number of vents (e.g. 7)

Even number of vents on one side

Even number of vents plus door

Even & odd number of vents on both sides (meeting stile)

Parni broj vrata na obe strane (sučeoni stil)
